Name: WNK Small Diameter 19mm Submersible Borehole Water Level Sensor for Deep Well
Brand: Hefei WNK Smart Technology Co.,Ltd
SKU: WNK8010-19
Price: 42.00 USD
Availability: InStock

Huis > producten > Waterspiegelzender >

WNK Small Diameter 19mm Submersible Borehole Water Level Sensor for Deep Well

19mm submersible water level sensor

deep well water level transmitter

small diameter borehole sensor

Plaats van herkomst:

Anhui, China

Merknaam:

WNK

Modelnummer:

WNK8010-19

Neem contact met ons op

Vraag een offerte

Productgegevens

Garantie:

1 jaar

Aangepaste ondersteuning:

OEM, ODM

Drukbereik::

0...2~200 meter

Uitvoer:

4-20mA, 0-5V, 1-5V, 0,5-4,5V, 0-10V

Nauwkeurigheid:

00,2% FS, 0,5% FS,

Stroomvoorziening:

12~36VDC

Beschermingsklasse:

IP68

Sollicitatie:

Regenwater, drinkwater, afvalwater, rioolwater, zeewater

Woningmateriaal:

304SS, 316L

Bedrijfstemperatuur::

-40~85 ℃

Type:

Graadmeter

OEM -service:

OEM, ODM, beschikbare aanpassing

Haven:

SHANGHAI/NINGBO

Markeren:

19mm submersible water level sensor

deep well water level transmitter

small diameter borehole sensor

Betalings- en verzendvoorwaarden

Min. bestelaantal

1 stks

Prijs

$35.00 - $50.00/Pieces

Verpakking Details

Elke set in één individuele doos, beschermd met schuim. Vervolgens in een omdoos.

Levertijd

5-8 werkdagen

Betalingscondities

T/T, Western Union, MoneyGram, PayPal

Levering vermogen

2000 stuks/stuk per maand

Gerelateerde producten

Video

WNK ATEX Explosion Proof LCD Display Liquid Level Sensor With 4-20mA for Water Tank

Vind de beste prijs

Video

WNK Small Diameter 19mm Submersible Borehole Water Level Sensor for Deep Well

Vind de beste prijs

Video

WNK Submersible Hydrostatic Water Level Sensor Probe for River Tank Liquid Level Transmission Pressure Transmitter

Vind de beste prijs

Video

316L Stainless Steel 4-20mA RS485 1-10V Liquid Level Transmitter Submersible Water Diesel Fuel Tank Level Sensors

Vind de beste prijs

Neem contact met ons op

Contact opnemen

Productbeschrijving

Product Description

Output	4-20mA, 0-5V, 1-5V, customization
Measured Range	0-0.5~200mH2O
Max overload	150% of sensor range
Pressure Type	Gage,Absolute
Accuracy	±0.2% FS/year
Long Term Stability	±0.25% FS/year
Housing Material	Stainless steel
Cable Material	Polyvinyl Fluoride, PTFE
Power supply	24V DC
Operating Temperature	-30~85℃
Compensation Temperature	-20~70℃
Protection Class	IP68

WNK8010-19 deep well water level sensor has high accuracy, small volume,stability,plus resistance to abrasion,oil,acid&alkali and high intensity gas lead cable ensured that it can meet the different occasions measurement requirements.

no-polarity two wire current output.

♦ It is widely used in well, standpipe, borewell, sewage, river and lakes treatment as well as channel, large rivers, l reservoirs and coastline monitoring.

♦ This product has got intrinsic safety certification,explosion proof certification and CE certification.

Applications

• Water tank level measurement and control.
• Fuel tank level measurement and monitor (diesel, gasoline, kerosene and so on).
• Liquid level measuring in tank, rivers, lake, sea, well, tube, underground water and so on.
• Special occasion such as high temperature liquid (up to 100 degree C), strongly corrosion liquid level measurement (request by customized.)

Features
• Adopting diffusion silicon oil-filled sensor
• Max measure range up to 200 meters or more
• High Stability, provide 0.1, 0.2, 0.5 accuracy for option
• Factory direct price

Size/Principle
